Full Duplex

80C200

HURRICANE

Full Duplex CMOS Ethernet

10/100 Mega Bit/Sec Data Link Controller

98203

Features

Low Power CMOS Technology

10/100 MBit Ethernet Controller Optimized for

Switching Hub, Multiport Bridge/Router, &

Server Applications

Meets ANSI/IEEE 802.3 and ISO 8802-3 Standards

for Ethernet (10Base-5) Thin Net (10Base-2)

(10Base-T) and the Proposed 100Base-T4,

100Base-TX Standards

Programmable MII Ethernet Interface for 10/100

MBit/sec Applications

Programmability of Double Word Threshold

Count for Space Available/Data Available Ready

Condition for Transmit/Receive FIFOs

Auto Retransmit Upon Collision Sense

Preamble Generation and Removal

Automatic 32-Bit FCS (CRC) Generation and

Checking

Collision Handling, Transmission Deferral and

Retransmission with Automatic Jam and

Backoff Functions

Error Interrupt and Status Generation

Selectable Little Endian/Big Endian Transmit Byte

Ordering for FIFO Interface for Intel/Motorola

Compatibility

Single 5 V

鹵

5% Power Supply

Standard CPU and Peripheral Interface

Control Signals

128/128 Byte Independent Transmit/Receive FIFOs

with 32 Bit Data Path Interface

- 1 G Bits/sec (133 M Bytes/sec) Peak Data Rate

in 32 Bit Mode.

Loopback Capability for Diagnostics

32 Bit FIFO Data Path

Inputs and Outputs TTL Compatible

The Following Additional Features can be

Programmed for the 80C200

- 64 bit Multicast Filter

- Reports Status of 鈥淪QE鈥?During Transmits

- Transmit No CRC Mode

- Transmit No Preamble Mode

- Transmit Packet Autopadding Mode

- Receive CRC Mode

- Disable Self-Receive on Transmit Mode

- Disable Further Transmissions when Both

Transmit Status Registers are Full

Note: Check for latest Data Sheet revision before

starting any designs.

SEEQ Data Sheets are now on the Web, at

www.lsilogic.com.

This document is an LSI Logic document. Any

reference to SEEQ Technology should be

considered LSI Logic.

- Disable Loading the Transmit Status for

Successfully Transmitted Packets

- Disable the Receive Interrupts Independent

of the Receive Command Register Setting

- Successful Packet Transmit Completion

Feature

Full Duplex Operation

- Provides 20/200 Mbps Bandwidthfor

Switched Networks

Transmit Status on a Per Packet Basis Reports the

Following

- Occurrence of a Transmit FIFO Underflow

- Transmit Collision Occurrence

- 16 Collision Occurrence

- Carrier Sense Error During Transmission

- 10/100 Mbit/sec Transmit Clock Detect

- Late Collision Occurrence

- Transmission Successful

- Transmission Deferred

Management Counters for

- Alignment Errors

- FCS Errors

- Runt Receive Frames

- Short Receive Events

- Oversized Receive Packets

- Transmit Collisions

- Receive Collisions

- Very Long Transmit Events

- Excessive Transmit Deferral

- Late Transmit Collisions

- Transmit Excessive Collisions

- Symbol Errors (100 MBit/sec Ethernet Only)

- Total Octets Received

- Total Octets Transmitted

- Receive FIFO Overflows

- Total Rx Multicast, Unicast and Broadcast

Frames

- Total Tx Multicast, Unicast and Broadcast

Frames

- Tx Defer Count

- Number of Retransmit Attempts

128 Pin PQFP package

Hurricane is a trademark of SEEQ Technology Inc.

4-1

MD400179/鈥?/div>
