SPECIAL ENVIRONMENT 80960CF-30 -25 -16
32-BIT HIGH-PERFORMANCE SUPERSCALAR
PROCESSOR

Socket and Object Code Compatible with 80960CA

Two Instructions Clock Sustained Execution

Four 59 Mbytes s DMA Channels with Data Chaining

Demultiplexed 32-bit Burst Bus with Pipelining
Y
32-bit Parallel Architecture
Two Instructions clock Execution
Load Store Architecture
Sixteen 32-bit Global Registers
Sixteen 32-bit Local Registers
Manipulate 64-bit Bit Fields
11 Addressing Modes
Full Parallel Fault Model
Supervisor Protection Model
Fast Procedure Call Return Model
Full Procedure Call in 4 clocks
On-Chip Register Cache
Caches Registers on Call Ret
Minimum of 6 Frames provided
Up to 15 Programmable Frames
On-Chip Instruction Cache
4 Kbyte Two-Way Set Associative
128-bit Path to Instruction Sequencer
Cache-Lock Modes
Cache-Off Mode
On-Chip Data Cache
1 Kbyte Direct-Mapped
Write Through
128 bits per Clock Access on
Cache Hit
Product Grades Available
SE3
b
40 C to
a
110 C
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
High Bandwidth On-Chip Data RAM
1 Kbytes On-Chip RAM for Data
Sustain 128 bits per clock access
Four On-Chip DMA Channels
59 Mbytes s Fly-by Transfers
32 Mbytes s Two-Cycle Transfers
Data Chaining
Data Packing Unpacking
Programmable Priority Method
32-Bit Demultiplexed Burst Bus
128-bit Internal Data Paths to
and
from Registers
Burst Bus for DRAM Interfacing
Address Pipelining Option
Fully Programmable Wait States
Supports 8 16 or 32-bit Bus Widths
Supports Unaligned Accesses
Supervisor Protection Pin
Selectable Big or Little Endian Byte
Ordering
High-Speed Interrupt Controller
Up to 248 External Interrupts
32 Fully Programmable Priorities
Multi-mode 8-bit Interrupt Port
Four Internal DMA Interrupts
Separate Non-maskable Interrupt Pin
Context Switch in 750 ns Typical
Other brands and names are the property of their respective owners
Information in this document is provided in connection with Intel products Intel assumes no liability whatsoever including infringement of any patent or
copyright for sale and use of Intel products except as provided in Intel鈥檚 Terms and Conditions of Sale for such products Intel retains the right to make
changes to these specifications at any time without notice Microcomputer Products may have minor variations to this specification known as errata
COPYRIGHT
INTEL CORPORATION 1995
January 1995
Order Number 271328-001
