78P2243
Triple E3/DS3/STS-1
Transceiver
Advanced Product Notice
June 2000
DESCRIPTION
The 78P2243 is a triple channel version of the
78P2241. Each of the three ports is a line interface
transceiver for E3, DS3, STS-1, North America T3 and
ATM applications. It includes clock recovery and
transmitter pulse shaping functions for applications
using 75-ohm coaxial cable at distances up to 1100
feet. These applications include DSLAMs, T3/E3 digital
multiplexers, SONET Add/Drop multiplexers, PDH
equipment, DS3 to Fiber optic and microwave modems
and ATM WAN access for routers and switches.
Each receiver recovers clock and data from a B3ZS or
HDB3-coded AMI signal. The receiver can compensate
for over 12dB of cable and 6dB of flat loss. The
transmitter has a B3ZS/HDB3 ENDEC with a receive
line code violation detector, a loop-back mode, a clock
polarity selection mode, and the ability to receive a
DSX3 monitor signal. Signals generated meet the
standard pulse shape requirements.
The 78P2243 is manufactured in an advanced
BiCMOS process and operates at both 3.3V and 5V
power supply voltages.
BLOCK DIAGRAM
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
Triple channel transmit and receive interface
for E3, DS3 and STS-1 applications
Interface to 75 ohm coaxial cable over 1100
feet at speeds up to 51.84 Mbit/s
Compliant with ANSI T1.102-1993, Telcordia GR-499-
CORE and GR-253-CORE, ITU-T G.703, G.823 and
G.824 for jitter tolerance and G.775 for loss of signal
Compliant with ATM FORUM af-phy-0034 (E3
public UNI) and af-phy-0054 (DS3 public UNI)
Easily Interfaced to ATM framer ICs such as
PMC-Sierra 7345 , and 7346 QJET
Receive DS3-high and DSX3 monitor signals
Diagnostic loop-back for AMI and digital signals
Selectable B3ZS/HDB3 ENDEC
Receive Line Code Violation Detector
128-lead TQFP package
3.3V or 5V operation
Input circuit works transformer or AC coupled
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Signal from
Adjacent Port
DLPBK
ENDEC
TPOS/TNRZ
TNEG
TCLK
B3ZS/
HDB3
Encoder
ENDEC
PULSE
SHAPER
TXEN
LBO
LOUTP
LOUTN
RPOS/RNRZ
RNEG/RLCV
B3ZS/
HDB3
Decoder
Data
Slicer
Adaptive
Equalizer
Clock
Reco very
LINP
LINN
RCLK
PWDN
Biasing
LF
RXLPBK
Signal
Detector
LOS
MON
Port 1
Port 2
Port 3
