74VCXH16240TTR Datasheet

  • 74VCXH16240TTR

  • BUFFER/DRIVER|QUAD|4-BIT|VCX-CMOS|TSSOP|48PIN|PLASTIC

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74VCXH16240
LOW VOLTAGE CMOS 16-BIT BUS BUFFER (3-STATE INV.)
WITH 3.6V TOLERANT INPUTS AND OUTPUTS
s
s
s
s
s
s
s
s
s
3.6V TOLERANT INPUTS AND OUTPUTS
HIGH SPEED :
t
PD
= 2.5 ns (MAX.) at V
CC
= 3.0 to 3.6V
t
PD
= 3.0 ns (MAX.) at V
CC
= 2.3 to 2.7V
POWER DOWN PROTECTION ON INPUTS
AND OUTPUTS
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24mA (MIN) at V
CC
= 3.0V
|I
OH
| = I
OL
= 18mA (MIN) at V
CC
= 2.3V
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2.3V to 3.6V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES H16240
BUS HOLD PROVIDED ON DATA INPUTS
LATCH-UP PERFORMANCE EXCEEDS
300mA (JESD 17)
ESD PERFORMANCE:
HBM > 2000V (MIL STD 883 method 3015);
MM > 200V
TSSOP
ORDER CODES
PACKAGE
TSSOP
TUBE
T&R
74VCXH16240TTR
PIN CONNECTION
DESCRIPTION
The 74VCXH16240 is a low voltage CMOS 16 BIT
BUS BUFFER (INVERTED) fabricated with
sub-micron silicon gate and five-layer metal wiring
C
2
MOS technology. It is ideal for low power and
very high speed 2.3 to 3.6V applications; it can be
interfaced to 3.6V signal environment for both
inputs and outputs.
Any nG output control governs four BUS
BUFFERS. Output Enable input (nG) tied together
gives full 16-bit operation.
When nG is LOW, the outputs are on. When nG is
HIGH, the output are in high impedance state.
This device is designed to be used with 3 state
memory address drivers, etc. Bus hold on data
inputs is provided in order to eliminate the need for
external pull-up or pull-down resistor.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
September 2001
1/10
