74LVXC4245M Datasheet

  • 74LVXC4245M

  • OCTAL DUAL SUPPLY BUS TRANSCEIVER

  • 181.02KB

  • 11頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

74LVXC4245
OCTAL DUAL SUPPLY BUS TRANSCEIVER
s
s
s
s
s
s
s
HIGH SPEED:
t
PD
= 6.5ns (MAX.) at
V
CCA
= 5.0V, V
CCB
= 5.0V
LOW POWER DISSIPATION:
I
CCA
= I
CCB
= 5碌A(MAX.) at T
A
=25擄C
LOW NOISE: V
OLP
=0.3V (TYP.) at
V
CCA
=5.0V V
CCB
=3.3V
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
OPERATING VOLTAGE RANGE:
V
CCA
(OPR) = 4.5V to 5.5V (1.2V Data Retention)
V
CCB
(OPR) = 2.7V to 5.5V (1.2V Data Retention)
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES C4245
IMPROVED LATCH-UP IMMUNITY
SOP
TSSOP
ORDER CODES
PACKAGE
SOP
TSSOP
TUBE
74LVXC4245M
T&R
74LVXC4245MTR
74LVXC4245TTR
DESCRIPTION
The 74LVXC4245 is a dual supply 8 bit
configurable low voltage CMOS OCTAL BUS
TRANSCEIVER fabricated with sub-micron silicon
gate and double-layer metal wiring C
2
MOS
technology. Designed for use as an interface
between a 5V bus and a 3.3V to 5V bus in a mixed
5V/3.3V supply systems, it achieves high speed
operation while maintaining the CMOS low power
dissipation.
PIN CONNECTION AND IEC LOGIC SYMBOLS
This IC is intended for two-way asynchronous
communication between data buses and the
direction of data transmission is determined by
DIR input. The enable input G can be used to
disable the device so that the buses are effectively
isolated.
The A-port interfaces with the 5V bus, the B-port
with the 3.3V to 5V bus.
All inputs are equipped with protection circuits
against static discharge, giving them 2KV ESD
immunity and transient excess voltage.
July 2001
1/11
