74LVQ240 Low Voltage Octal Buffer/Line Driver with 3-STATE Outputs
May 1998
74LVQ240
Low Voltage Octal Buffer/Line Driver with 3-STATE
Outputs
General Description
The LVQ240 is an inverting octal buffer and line driver de-
signed to be employed as a memory address driver, clock
driver and bus oriented transmitter or receiver which pro-
vides improved PC board density.
Features
n
Ideal for low power/low noise 3.3V applications
n
Implements patented EMI reduction circuitry
n
Available in SOIC JEDEC, SOIC EIAJ, and QSOP
packages
n
Guaranteed simultaneous switching noise level and
dynamic threshold performance
n
Improved latch-up immunity
n
Guaranteed incident wave switching into 75鈩?/div>
n
4 kV minimum ESD immunity
Ordering Code:
Order Number
74LVQ240SC
74LVQ240SJ
74LVQ240QSC
Package Number
M20B
M20D
MQA20
Package Description
20-Lead (0.300" Wide) Molded Small Outline Package, SOIC, JEDEC
20-Lead Molded Shrink Small Outline Package, SOIC, EIAJ
20-Lead (0.150" Wide) Molded Shrink Small Outline Package, SSOP, JEDEC
Devices also available in Tape and Reel. Specify by appending suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
IEEE/IEC
Connection Diagram
Pin Assignment,
SOIC and QSOP
DS011611-1
Pin Descriptions
Pin Names
OE
1
, OE
2
I
0
鈥揑
7
O
0
鈥揙
7
Inputs
Outputs
Description
3-STATE Output Enable Inputs
DS011611-2
Truth Tables
Inputs
OE
1
L
L
H
Inputs
OE
2
L
L
H
H = HIGH Voltage Level
X = Immaterial
Outputs
I
n
L
H
X
(Pins 12, 14, 16, 18)
H
L
Z
Outputs
I
n
L
H
X
L = LOW Voltage Level
Z = High Impedance
(Pins 3, 5, 7, 9)
H
L
Z
漏 1998 Fairchild Semiconductor Corporation
DS011611
www.fairchildsemi.com
