SN74LV161284
19-BIT BUS INTERFACE
SCLS426C 鈥?OCTOBER 1998 鈥?REVISED NOVEMBER 2002
D
D
D
D
D
D
4.5-V to 5.5-V V
CC
Operation
1.4-k鈩?Pullup Resistors Integrated on All
Open-Drain Outputs Eliminate the Need for
Discrete Resistors
Designed for IEEE Std 1284-I (Level-1 Type)
and IEEE Std 1284-II (Level-2 Type)
Electrical Specifications
Flow-Through Architecture Optimizes PCB
Layout
Latch-Up Performance Exceeds 250 mA Per
JEDEC 17
ESD Protection Exceeds JESD 22
鈥?4000-V Human-Body Model (A114-A)
鈥?300-V Machine Model (A115-A)
鈥?2000-V Charged-Device Model (C101)
DGG OR DL PACKAGE
(TOP VIEW)
description/ordering information
The SN74LV161284 is designed for 4.5-V to
5.5-V V
CC
operation. This device provides
asynchronous two-way communication between
data buses. The control-function implementation
minimizes external timing requirements.
This device has eight bidirectional bits; data can
flow in the A-to-B direction when DIR is high, and
in the B-to-A direction when DIR is low. This
device also has five drivers, which drive the cable
side, and four receivers. The SN74LV161284 has
one receiver dedicated to the HOST LOGIC line
and a driver to drive the PERI LOGIC line.
HD
A9
A10
A11
A12
A13
V
CC
A1
A2
GND
A3
A4
A5
A6
GND
A7
A8
V
CC
PERI LOGIC IN
A14
A15
A16
A17
HOST LOGIC OUT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
DIR
Y9
Y10
Y11
Y12
Y13
V
CC
CABLE
B1
B2
GND
B3
B4
B5
B6
GND
B7
B8
V
CC
CABLE
PERI LOGIC OUT
C14
C15
C16
C17
HOST LOGIC IN
The output drive mode is determined by the high-drive (HD) control pin. When HD is high, the B, Y, and
PERI LOGIC OUT outputs are in a totem-pole configuration, and in an open-drain configuration when HD is low.
This meets the drive requirements as specified in the IEEE Std 1284-I (level-1 type) and IEEE Std 1284-II
(level-2 type) parallel peripheral-interface specifications. Except for HOST LOGIC IN and PERI LOGIC OUT,
all cable-side pins have a 1.4-k鈩?integrated pullup resistor. The pullup resistor is switched off if the associated
output driver is in the low state or if the output voltage is above V
CC
CABLE. If V
CC
CABLE is off,
PERI LOGIC OUT is set to low.
The device has two supply voltages. V
CC
is designed for 4.5-V to 5.5-V operation. V
CC
CABLE supplies the
output buffers of the cable side only and is designed for 4.5-V to 5.5-V operation.
ORDERING INFORMATION
TA
SSOP 鈥?DL
PACKAGE鈥?/div>
Tube
Tape and reel
ORDERABLE
PART NUMBER
SN74LV161284DL
SN74LV161284DLR
TOP-SIDE
MARKING
LV161284
鈥?0擄C to 85擄C
TSSOP 鈥?DGG
Tape and reel
SN74LV161284DGGR
LV161284
鈥?Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines are
available at www.ti.com/sc/package.
