54F 74F545 Octal Bidirectional Transceiver with TRI-STATE Outputs
May 1995
54F 74F545 Octal Bidirectional
Transceiver with TRI-STATE Outputs
General Description
The 鈥橣545 is an 8-bit TRI-STATE high-speed transceiver It
provides bidirectional drive for bus-oriented microprocessor
and digital communications systems Straight through bidi-
rectional transceivers are featured with 24 mA (20 mA Mil)
bus drive capability on the A ports and 64 mA (48 mA Mil)
bus drive capability on the B ports
One input Transmit Receive (T R) determines the direction
of logic signals through the bidirectional transceiver Trans-
mit enables data from A ports to B ports Receive enables
data from B ports to A ports The Output Enable input dis-
ables both A and B ports by placing them in a TRI-STATE
condition
Features
Y
Y
Y
Y
Y
Y
Y
Higher drive than 8304
8-bit bidirectional data flow reduces system package
count
TRI-STATE inputs outputs for interfacing with bus-ori-
ented systems
24 mA (20 mA Mil) and 64 mA (48 mA Mil) bus drive
capability on A and B ports respectively
Transmit Receive and Output Enable simplify control
logic
Guaranteed 4000V minimum ESD protection
Pin for Pin compatible with Intel 8286
Commercial
74F545PC
Military
Package
Number
N20A
Package Description
20-Lead (0 300 Wide) Molded Dual-In-Line
20-Lead Ceramic Dual-In-Line
20-Lead (0 300 Wide) Molded Small Outline JEDEC
20-Lead (0 300 Wide) Molded Small Outline EIAJ
20-Lead Cerpack
20-Lead Ceramic Leadless Chip Carrier Type C
54F545DM (Note 2)
74F545SC (Note 1)
74F545SJ (Note 1)
54F545FM (Note 2)
54F545LM (Note 2)
J20A
M20B
M20D
W20A
E20A
Note 1
Devices also available in 13 reel Use suffix
e
SCX and SJX
Note 2
Military grade device with environmental and burn-in processing Use suffix
e
DMQB FMQB and LMQB
Logic Symbols
TL F 9556 鈥?3
IEEE IEC
TL F 9556 鈥?5
TRI-STATE is a registered trademark of National Semiconductor Corporation
C
1995 National Semiconductor Corporation
TL F 9556
RRD-B30M105 Printed in U S A

74F545SC 產品屬性

  • 1,080

  • 集成電路 (IC)

  • 邏輯 - 緩沖器，驅動器，接收器，收發器

  • 74F

  • 收發器，非反相

  • 1

  • 8

  • 3mA，24mA

  • 4.5 V ~ 5.5 V

  • 0°C ~ 70°C

  • 表面貼裝

  • 20-SOIC（0.295"，7.50mm 寬）

  • 20-SOIC

  • 管件
