74ALVC16374 Datasheet

  • 74ALVC16374

  • Low Voltage 16-Bit D-Type Flip-Flop

  • fairchild

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74ALVC16374 Low Voltage 16-Bit D-Type Flip-Flop with 3.6V Tolerant Inputs and Outputs
October 2001
Revised May 2005
74ALVC16374
Low Voltage 16-Bit D-Type Flip-Flop
with 3.6V Tolerant Inputs and Outputs
General Description
The ALVC16374 contains sixteen non-inverting D-type flip-
flops with 3-STATE outputs and is intended for bus oriented
applications. The device is byte controlled. A buffered clock
(CP) and output enable (OE) are common to each byte and
can be shorted together for full 16-bit operation.
The 74ALVC16374 is designed for low voltage (1.65V to
3.6V) V
CC
applications with I/O compatibility up to 3.6V.
The 74ALVC16374 is fabricated with an advanced CMOS
technology to achieve high speed operation while maintain-
ing low CMOS power dissipation.
Features
s
1.65V - 3.6V V
CC
supply operation
s
3.6V tolerant inputs and outputs
s
t
PD
3.5 ns max for 3.0V to 3.6V V
CC
4.4 ns max for 2.3V to 2.7V V
CC
7.8 ns max for 1.65V to 1.95V V
CC
s
Power-off high impedance inputs and outputs
s
Supports live insertion and withdrawal (Note 1)
s
Uses patented noise/EMI reduction circuitry
s
Latchup conforms to JEDEC JED78
s
ESD performance:
Human body model
!
2000V
Machine model
!
200V
s
Also packaged in plastic Fine-Pitch Ball Grid Array
(FBGA)
Note 1:
To ensure the high-impedance state during power up or power
down, OE should be tied to V
CC
through a pull-up resistor; the minimum
value of the resistor is determined by the current-sourcing capability of the
driver.
Ordering Code:
Order Number
74ALVC16374GX
(Note 2)
74ALVC16374MTD
(Note 3)
Package Number
BGA54A
MTD48
Package Descriptions
54-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
[TAPE and REEL]
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Note 2:
BGA package available in Tape and Reel only.
Note 3:
Devices also available in Tape and Reel. Specify by appending suffix letter 鈥淴鈥?to the ordering code.
漏 2005 Fairchild Semiconductor Corporation
DS500692
www.fairchildsemi.com
