74ALVC16244 Low Voltage 16-Bit Buffer/Line Driver with 3.6V Tolerant Inputs and Outputs
October 2001
Revised May 2005
74ALVC16244
Low Voltage 16-Bit Buffer/Line Driver
with 3.6V Tolerant Inputs and Outputs
General Description
The ALVC16244 contains sixteen non-inverting buffers with
3-STATE outputs to be employed as a memory and
address driver, clock driver, or bus oriented transmitter/
receiver. The device is nibble (4-bit) controlled. Each nibble
has separate 3-STATE control inputs which can be shorted
together for full 16-bit operation.
The 74ALVC16244 is designed for low voltage (1.65V to
3.6V) V
CC
applications with I/O capability up to 3.6V.
The 74ALVC16244 is fabricated with an advanced CMOS
technology to achieve high speed operation while maintain-
ing low CMOS power dissipation.
Features
s
1.65V鈥?.6V V
CC
supply operation
s
3.6V tolerant inputs and outputs
s
t
PD
3.0 ns max for 3.0V to 3.6V V
CC
3.5 ns max for 2.3V to 2.7V V
CC
6.0 ns max for 1.65V to 1.95V V
CC
s
Power-off high impedance inputs and outputs
s
Supports live insertion and withdrawal (Note 1)
s
Uses patented noise/EMI reduction circuitry
s
Latch-up conforms to JEDEC JED98
s
ESD performance:
Human body model
!
2000V
Machine model
!
200V
s
Also packaged in plastic Fine-Pitch Ball Grid Array
(FBGA)
Note 1:
To ensure the high-impedance state during power up or power
down, OE should be tied to V
CC
through a pull-up resistor; the minimum
value of the resistor is determined by the current-sourcing capability of the
driver.
Ordering Code:
Order Number
74ALVC16244GX
(Note 2)
74ALVC16244MTD
(Note 3)
Package Number
BGA54A
MTD48
Package Description
54-Ball Fine-Pitch Ball Grid Array (FBGA), JEDEC MO-205, 5.5mm Wide
[Tape and Reel]
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Note 2:
BGA package available in Tape and Reel only.
Note 3:
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
漏 2005 Fairchild Semiconductor Corporation
DS500677
www.fairchildsemi.com

74ALVC16244MTD 產品屬性

  • 38

  • 集成電路 (IC)

  • 邏輯 - 緩沖器，驅動器，接收器，收發器

  • 74ALVC

  • 緩沖器/線路驅動器，非反相

  • 4

  • 4

  • 24mA，24mA

  • 1.65 V ~ 3.6 V

  • -40°C ~ 85°C

  • 表面貼裝

  • 48-TFSOP（0.240"，6.10mm 寬）

  • 48-TSSOP

  • 管件
