74ALVC16240/D Datasheet

  • 74ALVC16240/D

  • Low-Voltage 1.8/2.5/3.3 V 16-Bit Buffer

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74ALVC16240
Low-Voltage 1.8/2.5/3.3 V
16-Bit Buffer
With 3.6 V鈥揟olerant Inputs and Outputs
(3鈥揝tate, Inverting)
The 74ALVC16240 is an advanced performance, inverting 16鈥揵it
buffer. It is designed for very high鈥搒peed, very low鈥損ower operation
in 1.8 V, 2.5 V or 3.3 V systems.
The 74ALVC16240 is nibble controlled with each nibble
functioning identically, but independently. The control pins may be
tied together to obtain full 16鈥揵it operation. The 3鈥搒tate outputs are
controlled by an Output Enable (OEn) input for each nibble. When
OEn is LOW, the outputs are on. When OEn is HIGH, the outputs are
in the high impedance state.
http://onsemi.com
MARKING DIAGRAM
48
48
74ALVC16240DT
1
AWLYYWW
鈥?/div>
Designed for Low Voltage Operation: V
CC
= 1.65鈥?.6 V
鈥?/div>
3.6V Tolerant Inputs and Outputs
鈥?/div>
High Speed Operation: 3.0 ns max for 3.0 to 3.6 V
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
3.7 ns max for 2.3 to 2.7 V
6.0 ns max for 1.65 to 1.95 V
Static Drive:
鹵24
mA Drive at 3.0 V
鹵12
mA Drive at 2.3 V
鹵4
mA Drive at 1.65 V
Supports Live Insertion and Withdrawal
I
OFF
Specification Guarantees High Impedance When V
CC
= 0 V
鈥?/div>
Near Zero Static Supply Current in All Three Logic States (40
mA)
Substantially Reduces System Power Requirements
Latchup Performance Exceeds
鹵250
mA @ 125擄C
ESD Performance: Human Body Model >2000 V;
Machine Model >200 V
Second Source to Industry Standard 74ALVC16240
TSSOP鈥?8
DT SUFFIX
CASE 1201
A
WL
YY
WW
1
= Assembly Location
= Wafer Lot
= Year
= Work Week
ORDERING INFORMATION
Device
74ALVC16240DTR
Package
TSSOP
Shipping
2500/Tape & Reel
鈥燭o ensure the outputs activate in the 3鈥搒tate condition, the output enable pins
should be connected to V
CC
through a pull鈥搖p resistor. The value of the resistor is
determined by the current sinking capability of the output connected to the OE pin.
漏
Semiconductor Components Industries, LLC, 2002
1
July, 2002 鈥?Rev. 0
Publication Order Number:
74ALVC16240/D
