74ACTQ16244 16-Bit Buffer/Line Driver with 3-STATE Outputs
May 1991
Revised November 1999
74ACTQ16244
16-Bit Buffer/Line Driver with 3-STATE Outputs
General Description
The ACTQ16244 contains sixteen non-inverting buffers
with 3-STATE outputs designed to be employed as a mem-
ory and address driver, clock driver, or bus oriented trans-
mitter/receiver. The device is nibble controlled. Each nibble
has separate 3-STATE control inputs which can be shorted
together for full 16-bit operation.
The ACTQ16244 utilizes Fairchild鈥檚 Quiet Series technol-
ogy to guarantee quiet output switching and improved
dynamic threshold performance. FACT Quiet Series錚?fea-
tures GTO錚?output control for superior performance.
Features
s
Utilizes Fairchild鈥檚 FACT Quiet Series technology
s
Guaranteed simultaneous switching noise level and
dynamic threshold performance
s
Guaranteed pin-to-pin output skew
s
Separate control logic for each byte and nibble
s
16-bit version of the ACTQ244
s
Outputs source/sink 24 mA
s
Additional specs for multiple output switching
s
Output loading specs for both 50 pF and 250 pF loads
Ordering Code:
Order Number
74ACTQ16244SSC
74ACTQ16244MTD
Package Number
MS48A
MTD48
Package Description
48-Lead Small Shrink Outline Package (SSOP), JEDEC MO-118, 0.300鈥?Wide
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Device also available in Tape and Reel. Specify by appending suffix letter 鈥淴鈥?to the ordering code.
Logic Symbol
Pin Description
Pin Names
OE
n
I
0
鈥揑
15
O
0
鈥揙
15
Description
Output Enable Input (Active LOW)
Inputs
Outputs
FACT錚? FACT Quiet Series錚? and GTO錚?are trademarks of Fairchild Semiconductor Corporation.
漏 1999 Fairchild Semiconductor Corporation
DS010925
www.fairchildsemi.com
