74AC14 Datasheet

  • 74AC14

  • HEX INVERTER

  • 7頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

74AC14
HEX INVERTER
s
s
s
s
s
s
s
s
s
HIGH SPEED: t
PD
= 6 ns (TYP.) at V
CC
= 3.3V
LOW POWER DISSIPATION:
I
CC
= 4
碌A(chǔ)
(MAX.) at T
A
= 25
o
C
HIGH NOISE IMMUNITY:
V
NIH
= V
NIL
= 28% V
CC
(MIN.)
50鈩?TRANSMISSION LINE DRIVING
CAPABILITY
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 24 mA (MIN)
BALANCED PROPAGATION DELAYS:
t
PLH
鈮?/div>
t
PHL
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2V to 6V
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 14
IMPROVED LATCH-UP IMMUNITY
B
M
(Plastic Package)
(Micro Package)
ORDER CODES :
74AC14B
74AC14M
equivalent Bipolar Shottky TTL.
The internal circuit is composed of 3 stages
including buffer output, which enables high noise
immunity and stable output.
This together with its schmitt trigger function
allows it to be used on line receivers with slow
rise/fall input segnals.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
DESCRIPTION
The AC14 is an advanced high-speed CMOS
HEX INVERTER fabricated with sub-micron
silicon gate and double-layer metal wiring C
2
MOS
technology. It is ideal for low power applications
mantaining high speed operation similar to
PIN CONNECTION AND IEC LOGIC SYMBOLS
March 1998
1/7
