74ABT16652 16-Bit Transceivers and Registers with 3-STATE Outputs
April 1993
Revised January 1999
74ABT16652
16-Bit Transceivers and Registers with 3-STATE Outputs
General Description
The ABT16652 consists of sixteen bus transceiver circuits
with D-type flip-flops, and control circuitry arranged for mul-
tiplexed transmission of data directly from the input bus or
from the internal registers. Each byte has separate control
inputs which can be shorted together for full 16-bit opera-
tion. Data on the A or B bus will be clocked into the regis-
ters as the appropriate clock pin goes to HIGH logic level.
Output Enable pins (OEAB, OEBA) are provided to control
the transceiver function.
Features
s
Independent registers for A and B buses
s
Multiplexed real-time and stored data
s
Separate control logic for each byte
s
A and B output sink capability of 64 mA, source
capability of 32 mA
s
Guaranteed output skew
s
High impedance glitch free bus loading during entire
power up and power down cycle
s
Nondestructive hot insertion capability
Ordering Code:
Order Number
74ABT16652CSSC
74ABT16652CMTD
Package Number
MS56A
MTD56
Package Description
56-Lead Shrink Small Outline Package (SSOP), JEDEC MO-118, 0.300鈥?Wide
56-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter 鈥淴鈥?to the ordering code.
Pin Descriptions
Pin Names
A
0
鈥揂
16
Descriptions
Data Register A Inputs/
3-STATE Outputs
B
0
鈥揃
16
Data Register B Inputs/
3-STATE Outputs
CPAB
n
, CPBA
n
SAB
n
, SBA
n
OEAB
n
, OEBA
n
Clock Pulse Inputs
Select Inputs
Output Enable Inputs
