SIDE-LOOK PACKAGE

PIN PHOTODIODE

Description

The MID-73A1C is a photodiode mounted in special

dark plastic package and suitable for the IRED (940nm)

Type.

3.05

(.120)

MID-73A1C

Package Dimensions

Unit : mm (inches )

7.5鹵0.12

(..295

3.00+0.120

(.118鹵.005)

SEE NOTE 2

5.2鹵0.12

(.205鹵.005)

RADIANT SENSITIVE AREA

ANODE

16.00 MIN.

(.630)

Features

l

l

l

l

0.50 TYP.

(.020)

1.00MIN.

(.039)

2.54 NOM.

(.100)

SEE NOTE 3

High photo sensitivity

Low junction capacitance

High cut-off frequency

Fast switching time

A

C

Notes :

1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.

2. Protruded resin under flange is 1.0 mm (.040") max.

3. Lead spacing is measured where the leads emerge from the package.

Absolute Maximum Ratings

@ T

A

=25

o

C

Parameter

Power Dissipation

Operating Temperature Range

Storage Temperature Range

Lead Soldering Temperature

Maximum Rating

100

-55

o

C to +100

o

C

-55

o

C to +100

o

C

260

o

C for 5 seconds

Unit

mW

Unity Opto Technology Co., Ltd.

02/04/2002
