Appliances
Data loggers
Industrial equipment
Automotive body electronics
FEATURES
HIGH-PERFORMANCE 68HC08 CPU CORE
鈥?8 MHz bus operation at 5V operation for
125 nsec minimum instruction cycle time
鈥?Efficient instruction set including multiply
and divide
鈥?16 flexible addressing modes including stack
relative with 16-bit stack pointer
鈥?Fully static low-voltage, low-power design
with wait and stop modes
BENEFITS
鈥?Object code compatible with the 68HC05
鈥?Easy to learn and use architecture
鈥?C optimized architecture provides
compact code
Freescale Semiconductor, Inc...
The 68HC908AB32 FLASH microcontroller
utilizes Motorola鈥檚 highly successful 68HC08
architecture and is code compatible with
68HC05 microcontrollers providing an efficient
migration path to higher performance FLASH
MCUs. With 32,256 bytes of in-system,
programmable FLASH memory and in-circuit
programming capability, the 68HC908AB32
delivers high-performance while lowering
costs. The 68HC908AB32 provides security
and reliability with innovative features like a
computer operating properly (COP) watchdog,
selectable FLASH security, memory-mapped
input/output registers, low-voltage inhibit
(LVI) and stop and wait modes.
INTEGRATED SECOND GENERATION FLASH MEMORY
鈥?In-application re-programmable
鈥?Extremely fast programming, encoding
64 bytes in as fast as 2 msec
鈥?FLASH programming across the 68HC08鈥檚
full operating supply voltage with no extra
programming voltage
鈥?10K write/erase cycles minimum over
temperature
鈥?Flexible block protection and security
鈥?Cost-effective programming changes and
field software upgrades via in-application
programmability and re-programmability
鈥?Reduces production programming costs
through ultra-fast programming
鈥?Allows re-programmable battery-powered
applications
鈥?Byte-writable for data as well as program
memory
鈥?Protects code from unauthorized reading and
to guard against unintentional
erasing/writing of user-programmable
segments of code
INTEGRATED EEPROM
HC08 CPU
KBI
鈥?Byte erasable
32K Flash
8-ch 8-bit
ADC
8-BIT ANALOG-TO-DIGITAL CONVERTER
鈥?8 channels
鈥?Single conversion in 17 碌sec
鈥?Fast, easy conversion from analog inputs like
temperature, pressure, and fluid levels to
digital values for CPU processing
1K RAM
512 EEPROM
SCI
SPI
4-ch + 4-ch
16-bit Timer
CLOCK GENERATION MODULE WITH PLL
鈥?Programmable clock frequency in integer
multiples of external crystal reference
鈥?Crystal reference of 1 MHz to 8 MHz
鈥?External clock option with or without PLL
鈥?Provides high performance using low-cost,
low-frequency reference crystals
鈥?Reduces generated noise while still
providing high performance (up to 32 MHz
internal clock)
COP
8 PROGRAMMABLE 16-BIT TIMER CHANNELS
LVI
51 GPIO
鈥?125 nsec resolution at 8 MHz bus
鈥?Free-running counter or modulo up-counter
鈥?Each channel independently programmable
for input capture, output compare or
unbuffered PWM
鈥?Pairing timer channels provides a buffered
PWM function
