ELLIPSE (4.7X5.7) PACKAGE
SOLID STATE LAMP
Description
The MVL-663BK-S, a blue source color device, is made with
InGaN on SiC substrate LED die.
The package is ellipse transparent blue color plastic type.
7.70
(.312)
蠁4.70
(.191)
MVL-663BK-S
Package Dimensions
Unit: mm ( inches )
4.7
(.191)
Applications
l
l
l
l
l
Full Color Displays & Moving Message Signs
Solid State Incandescent Replacement Bulbs
High Ambient Panel Indicators
Color Printers & Scanners
Medical & Analytical Instruments
5.7
(.231)
SEE NOTE 2
3.70
(.150)
1.5 0
(.060)
0.50 TYP.
(.020)
25.40 MIN.
(1.000)
Features
l
l
l
l
l
l
High Performance - 2.5mW (470nm)
Superior SiC Substrate Technology
Excellent Chip to Chip Consistency
High Reliability
Stopper
Coting
A
1.00MIN.
(.040)
2.54TYP.
(.100)
SEE NOTE 3
C
Notes :
1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 0.8 mm (.031") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Peak Forward Current(1/10 Duty Cycle@1KHz )
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Electrostatic Discharge Threshold(HBM)
Solder temperature 1.6 mm from body for 5 seconds at 260
o
C
Symbol
I
pf
I
af
V
R
T
opr
T
stg
E
ot
Unit
Maximum Rating
mA
100
mA
30
V
5
o
o
-20
C
to +80
C
-30
o
C
to +100
o
C
V
1000
