TEDEA
- HUNTLEIGH
Model 620
聭S聮 Type Load Cell
Model 620 is an advanced concept
in providing the weighing industry
with the ultimate protection
necessary for today聮s hostile
weighing environment.
Its all welded sealing combined
with high accuracy, make this
load cell ideally suited for lever
conversions, hopper / tanks and
vibratory feeders, general process
weighing and force measurement
applications. It is approved by
OIML to R60, up to 3000 divisions.
Hermetically sealed against
moisture, the construction of
the model 620 combined with
polyurethane dual shielded cable
enables the load cell to function
in harsh environments whilst
maintaining its operating
specifications.
The two additional sense wires
feed back the voltage reaching the
load cell. Complete compensation
of changes in lead resistance due
to temperature change and / or
cable extension, is achieved by
feeding this voltage into the
appropriate electronics.
路
路
路
路
路
路
Capacities: 500 - 5000 kg ( - lbs)
Stainless steel construction
Fully welded protection, to IP68
For use in tension & compression
6 Wire (sense) circuit
OIML, NTEP and EEx ia approved
info@tedea-huntleigh.com www.tedea-huntleigh.com
L
OS ANGELES,
USA D
ARMSTADT-
E
BERSTANDT,
G
ERMANY
B
EIJING,
C
HINA
C
ARDIFF,
UK N
ETANYA,
I
SRAEL
K
ARMIEL
, I
SRAEL
C
HARTRES,
F
RANCE
7800 Deering Avenue
路
P.O. Box 7964
路
Canoga Park, CA 91309-7964 USA
路
Tel: 800.626.2616
路
Fax: 818.340.1175
