Analog Switches
Signal Conditioning
Small Signal Amplifiers
High Density Packaging
DESCRIPTION
The
61096
is a hermetically sealed general purpose switching transistor in a TO-18 package. This rugged package is able to
withstand high acceleration loads and is ideal for designs where durability and device weight are important requirements. This
device is available custom binned to customer specifications or screened to MIL-PRF-19500.
ABSOLUTE MAXIMUM RATINGS
Collector-Base Voltage .............................................................................................................................................................. 75V
Collector-Emitter Voltage ........................................................................................................................................................... 50V
Emitter-Collector Voltage ............................................................................................................................................................. 6V
Continuous Collector Current................................................................................................................................................ 800mA
Power Dissipation (Derate at the rate of 3.33 mW/擄C above 25擄C) ..................................................................................500mW
Maximum Junction Temperature ......................................................................................................................................... +200擄C
Operating Temperature (See part selection guide for actual operating temperature) .........................................-65擄C to +200擄C
Storage Temperature .............................................................................................................................................-65擄C to +200擄C
Lead Soldering Temperature (vapor phase reflow for 30 seconds) ..................................................................................... 215擄C
Package Dimensions
Schematic Diagram
COLLECTOR
脴0.100 [脴2.54]
BASE
2
3
3
0.048
[1.22]
0.028
[0.71]
45擄
[1.17]
0.046
[0.91]
0.036
C
1
EMITTER
1
E
B
2
0.230脴 (5.84)
0.209脴 (5.31)
0.195脴 (4.95)
0.178脴 (4.52)
3 LEADS
0.021脴 [0.53]
0.016脴 [0.41]
0.030 [0.76)] MAX
0.500脴 ([12.70] MAX
0.750脴 [19.05] MIN
0.210
[5.33]
0.170
[4.32]
DIMENSIONS ARE IN INCHES (MILLIMETERS)
MICROPAC INDUSTRIES, INC. OPTOELECTRONIC PRODUCTS DIVISION
鈥?/div>
725 E.Walnut Str., Garland, TX 75040
鈥?/div>
(972)272-3571
鈥?/div>
Fax (972)487-6918
www.micropac.com
E-MAIL: OPTOSALES @ MICROPAC.COM
