5KP5.0
DC COMPONENTS CO., LTD.
R
THRU
5KP180CA
RECTIFIER SPECIALISTS
TECHNICAL SPECIFICATIONS OF TRANSIENT VOLTAGE SUPPRESSOR
VOLTAGE RANGE - 5.0 to 180 Volts
PEAK PULSE POWER - 5000 Watts
FEATURES
* Glass passivated junction
* 5000 Watts Peak Pulse Power capability on
10/1000 碌s waveform
* Excellent clamping capability
* Low zener impedance
* Fast response time
R-6
MECHANICAL DATA
* Case: Molded plastic
* Epoxy: UL 94V-0 rate flame retardant
* Lead: MIL-STD-202E, Method 208 guaranteed
* Polarity: Color band denotes positive end (cathode)
except bidirectional types
* Mounting position: Any
* Weight: 2.1 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load,
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
o
DEVICES FOR BIPOLAR APPLICATIONS
For Bidirectional use C or CA suffix (e.g. 5KP5.0C, 5KP180CA).
Electrical characteristics apply in both directions
SYMBOL
Peak Pulse Power Dissipation on 10/1000 碌s waveform
(Note1,FIG.1)
Steady State Power Dissipation at T
L
= 75
o
C
Lead Lengths .375"(9.5mm) (Note 2)
Peak Forward Surge Current, 8.3ms single half sine-wave
superimposed on rated load( JEDEC Method ) (Note 3)
Maximum Instantaneous Forward Voltage at 100A for Unidirectional
Only
Operating and Storage Temperature Range
P
PPM
VALUE
Minimum 5000
UNITS
Watts
P
M(AV)
I
FSM
8.0
400
Watts
Amps
V
F
T
J
, T
STG
3.5
-55 to + 175
Volts
0
C
NOTES : 1. Non-repetitive current pulse, per Fig.3 and derated above T
A
= 25
o
C per Fig.2.
2. Mounted on Copper Leaf area of 0.8 X 0.8*( 20 X 20mm ) per Fig. 5
3. 8.3ms single half sine-wave or equivalent square wave, duty cycle = 4 pulses per minute maximum.
