5962-8950701CA Datasheet

  • 5962-8950701CA

  • High-Speed CMOS Logic Quad Bilateral Switch

  • 14頁

  • TI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

CD54HC4066, CD74HC4066,
CD74HCT4066
Data sheet acquired from Harris Semiconductor
SCHS208D
February 1998 - Revised August 2003
High-Speed CMOS Logic
Quad Bilateral Switch
Description
The 鈥橦C4066 and CD74HCT4066 contain four independent
digitally controlled analog switches that use silicon-gate
CMOS technology to achieve operating speeds similar to
LSTTL with the low power consumption of standard CMOS
integrated circuits.
These switches feature the characteristic linear 鈥淥N鈥?/div>
resistance of the metal-gate CD4066B. Each switch is
turned on by a high-level voltage on its control input.
Features
鈥?Wide Analog-Input-Voltage Range . . . . . . . . . . 0V - 10V
[ /Title
(CD74H
C4066,
CD74H
CT4066
)
/Subject
(High-
Speed
CMOS
Logic
Quad
鈥?Low 鈥淥N鈥?Resistance
- V
CC
= 4.5V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25鈩?/div>
- V
CC
= 9V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15鈩?/div>
鈥?Fast Switching and Propagation Delay Times
鈥?Low 鈥淥FF鈥?Leakage Current
鈥?Wide Operating Temperature Range . . . -55
o
C to 125
o
C
鈥?HC Types
- 2V to 10V Operation
- High Noise Immunity: N
IL
= 30%, N
IH
= 30% of V
CC
at V
CC
= 5V and 10V
鈥?HCT Types
- Direct LSTTL Input Logic Compatibility,
V
IL
= 0.8V (Max), V
IH
= 2V (Min)
- CMOS Input Compatibility, I
l
鈮?/div>
1碌A(chǔ) at V
OL
, V
OH
Ordering Information
PART NUMBER
CD54HC4066F3A
CD74HC4066E
CD74HC4066M
CD74HC4066MT
CD74HC4066M96
CD74HC4066PW
CD74HC4066PWR
CD74HC4066PWT
CD74HCT4066E
CD74HCT4066M
CD74HCT4066MT
CD74HCT4066M96
TEMP. RANGE
(
o
C)
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
PACKAGE
14 Ld CERDIP
14 Ld PDIP
14 Ld SOIC
14 Ld SOIC
14 Ld SOIC
14 Ld TSSOP
14 Ld TSSOP
14 Ld TSSOP
14 Ld PDIP
14 Ld SOIC
14 Ld SOIC
14 Ld SOIC
NOTE: When ordering, use the entire part number. The suf鏗亁es 96
and R denote tape and reel. The suf鏗亁 T denotes a small-quantity
reel of 250.
Pinout
CD54HC4066 (CERDIP)
CD74HC4066 (PDIP, SOIC, TSSOP)
CD74HCT4066 (PDIP, SOIC)
TOP VIEW
1Y 1
1Z 2
2Z 3
2Y 4
2E 5
3E 6
GND 7
14 V
CC
13 1E
12 4E
11 4Y
10 4Z
9 3Z
8 3Y
CAUTION: These devices are sensitive to electrostatic discharge. Users should follow proper IC Handling Procedures.
Copyright
漏
2003, Texas Instruments Incorporated
1
