T-1 3/4 (
蠁
5mm)
HIGH POWER AlInGaP LED LAMPs
Description
The MVL-584UG , a green source color device , is made with
tran AllnGaP light emitting diode.
The package is T-1 3/4 (蠁5mm) standard green transparent plastic
lens type.
5.00
(.197)
MVL-584UG
Package Dimensions
Unit: mm ( inches )
Features
l
l
l
l
6.80
(.268)
Standard T-1 3/4 (蠁5mm) package
Low power consumption
High efficiency
Reliable
24.00 MIN.
(0.945)
SEE NOTE 2
0.50 typ.
(.019)
1.00 min
(.039)
2.54 nom.
(.100)
SEE NOTE 3
A
C
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current(1/10 Duty Cycle100碌s pulse )
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Symbol
P
ad
I
pf
I
af
V
R
T
opr
T
stg
Maximum Rating
100
200
50
5
Unit
mW
mA
mA
V
-40
o
C
to +100
o
C
-40
o
C
to +100
o
C
Soldering Temperature 1.6 mm from body for 5 seconds at 260
o
C
Unity Opto Technology Co., Ltd.
09/05/2000
