T-1 3/4 (
蠁
5mm)
HIGH POWER AlInGaP LED LAMPs
Description
The MVL-584SO utilizes the latest absorbing
substrate Aluminum Indium Gallium Phosphide
(AlInGaP) LED technology. This LED material
has outstanding light output efficiency over a
wide range of drive current. The package is T-1
3/4 (5mm) water clear standard type.
6.80
(.268)
5.00
(.197)
MVL-584SO
Unit: mm ( inches )
Package Dimensions
SEE NOTE 2
Features
l
24.00 MIN.
(0.945)
Ultra - brightness
Low power consumption
TTL compatible
Reliable
A
0.50 typ.
(.019)
1.00 min
(.039)
2.54 nom.
(.100)
l
l
l
SEE NOTE 3
C
Notes :
1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 1.5 mm (.059") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current(1/10 Duty Cycle100碌s pulse width )
Continuous Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature 1.6 mm from body for 5 seconds at 260
o
C
Maximum Rating
125
100
50
5
-40
o
C
to +100
o
C
-40
o
C
to +100
o
C
Unit
mW
mA
mA
V
Unity Opto Technology Co., Ltd.
09/05/2000
1
2
