T-1 3/4 PACKAGE
NPN PHOTOTRANSISTOR
Description
The MID-57422 is a NPN silicon phototransistor
mounted in a lensed , water clear plastic package to fit
wide range of IR light source.
MID-57422
Package Dimensions
蠄5.05
(.200)
Unit : mm (inches )
5.47
(.215)
7.62
(.300)
5.90
(.230)
Features
l
l
l
l
l
1.00
(.040)
Wide range of collector current
Lensed for high sensitivity
Standard T-1 3/4 (5mm) package
Acceptance view angle : 70擄
Low cost plastic package
1.00MIN.
(.040)
2.54
(.100)
0.50TYP.
(.020)
23.40MIN.
(.920)
FLAT DENOTES COLLECTOR
E
C
Notes :
1.Tolerance is 鹵 0.25 mm(.010")unless otherwise noted.
2.Protruded resin under flange is 1.0 mm(.040")max.
3.Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25鈩?/div>
Parameter
Power Dissipation
Collector-Emitter Voltage
Emitter-Collector Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
150
30
5
-55鈩?to +100鈩?/div>
-55鈩?to +100鈩?/div>
260鈩?for 5 seconds
Unit
mW
V
V
07/21/2000
Unity Opto Technology Co., Ltd.
1
2
