T-1 3/4 PACKAGE

PIN PHOTODIODE

Description

The MID-56A19 is a photodiode mounted in

special dark end look plastic package and

suitable for the IRED 940nm type.

7.62

(.300)

5.90

(.230)

1.00

(.040)

MID-56A19

Package Dimensions

蠄5.05

(.200)

Unit: mm ( inches )

5.47

(.215)

FLAT DENOTES CATHOD

23.40 MIN.

(.920)

Features

l

l

l

l

l

.50 TYP.

(.020)

High photo sensitivity

Low junction capacitance

High cut-off frequency

Fast switching time

Acceptance viwe angle : 60擄

A

C

2.54

(.100)

1.00MIN.

(.040)

Notes :

1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.

2. Protruded resin under flange is 1.0 mm (.040") max.

3. Lead spacing is measured where the leads emerge from the package.

Absolute Maximum Ratings

@ T

A

=25

o

C

Parameter

Power Dissipation

Operating Temperature Range

Storage Temperature Range

Lead Soldering Temperature

Maximum Rating

150

-55

o

C to +100

o

C

-55

o

C to +100

o

C

260

o

C for 5 seconds

Unit

mW

Unity Opto Technology Co., Ltd.

02/04/2002
