MOTOROLA

SEMICONDUCTOR TECHNICAL DATA

Octal D-Type Latch

with 3-State Output

The MC74VHC373 is an advanced high speed CMOS octal latch with

3鈥搒tate output fabricated with silicon gate CMOS technology. It achieves

high speed operation similar to equivalent Bipolar Schottky TTL while

maintaining CMOS low power dissipation.

This 8鈥揵it D鈥搕ype latch is controlled by a latch enable input and an output

enable input. When the output enable input is high, the eight outputs are in a

high impedance state.

The internal circuit is composed of three stages, including a buffer output

which provides high noise immunity and stable output. The inputs tolerate

voltages up to 7V, allowing the interface of 5V systems to 3V systems.

鈥?/div>

High Speed: tPD = 5.0ns (Typ) at VCC = 5V

Low Power Dissipation: ICC = 4碌A(chǔ) (Max) at TA = 25擄C

High Noise Immunity: VNIH = VNIL = 28% VCC

Power Down Protection Provided on Inputs

Balanced Propagation Delays

Designed for 2V to 5.5V Operating Range

Low Noise: VOLP = 0.9V (Max)

Pin and Function Compatible with Other Standard Logic Families

Latchup Performance Exceeds 300mA

ESD Performance: HBM > 2000V; Machine Model > 200V

Chip Complexity: 186 FETs or 46.5 Equivalent Gates

MC74VHC373

DW SUFFIX

20鈥揕EAD SOIC PACKAGE

CASE 751D鈥?4

DT SUFFIX

20鈥揕EAD TSSOP PACKAGE

CASE 948E鈥?2

M SUFFIX

20鈥揕EAD SOIC EIAJ PACKAGE

CASE 967鈥?1

ORDERING INFORMATION

MC74VHCXXXDW

SOIC

MC74VHCXXXDT

TSSOP

MC74VHCXXXM

SOIC EIAJ

LOGIC DIAGRAM

D0

D1

D2

DATA

INPUTS

D3

D4

D5

D6

D7

3

4

7

8

13

14

17

18

2

5

6

9

12

15

16

19

Q0

Q1

Q2

Q3

Q4

Q5

Q6

Q7

NONINVERTING

OUTPUTS

PIN ASSIGNMENT

OE

Q0

D0

D1

Q1

Q2

D2

1

2

3

4

5

6

7

8

9

10

20

19

18

17

16

15

14

13

12

11

VCC

Q7

D7

D6

Q6

Q5

D5

D4

Q4

LE

OE

11

1

D3

Q3

GND

FUNCTION TABLE

INPUTS

OE

L

H

LE

H

L

X

D

H

L

X

OUTPUT

Q

H

L

No Change

Z

6/97

漏

Motorola, Inc. 1997

1

REV 1
