T-1 3/4 PACKAGE
NPN PHOTOTRANSISTOR
Description
The MID-54H22 is a NPN silicon phototransistor mounted
in a lensed, special dark plastic package. The lensing effect
of the package allows an acceptance view angle of 40
o
so
that the product performs a high directional characteristic.
7.62
(.300)
5.90
(.230)
1.00
(.040)
蠄5.05
(.200)
MID-54H22
Package Dimensions
Unit: mm ( inches )
5.47
(.215)
FLAT DENOTES COLLECTOR
Features
l
l
l
l
l
l
Wide range of collector current
Lensed for high sensitivity
Standard T-13/4 (5mm) package .
Acceptance viwe angle : 40
o
Low cost plastic package
Good spectral matching IRED (位p 880/850 nm) type
2.54
(.100)
.50 TYP.
(.020)
23.40 MIN.
(.920)
1.00MIN.
(.040)
E
C
Notes :
1.Tolerance is 鹵 0.25 mm (.010" ) unless otherwise noted.
2.Protruded resin under flange is 1.0 mm (.040") max.
3.Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
@ T
A
=25
o
C
Parameter
Power Dissipation
Collector-Emitter Voltage
Emitter-Collector Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
150
30
5
-55
o
C to +100
o
C
-55
o
C to +100
o
C
260
o
C for 5 seconds
Unit
mW
V
V
