54F74DMQB Datasheet

  • 54F74DMQB

  • FLIP-FLOP|DUAL|D TYPE|F-TTL|DIP|14PIN|CERAMIC

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MILITARY DATA SHEET
MN54F74-X REV 1A0
Original Creation Date: 03/13/96
Last Update Date: 07/30/96
Last Major Revision Date: 03/13/96
DUAL D-TYPE POSITIVE EDGE-TRIGGERED FLIP-FLOP
General Description
The F74 is a dual D-type flip-flop with Direct Clear and Set inputs and complementary
(Q/Q) outputs. Information at the input is transferred to the outputs on the positive
edge of the clock pulse. Clock triggering occurs at a voltage level of the clock pulse
and is not directly related to the transition time of the positive-going pulse. After the
Clock Pulse Input threshold voltage has been passed, the Data inputs is locked out and
information present will not be transferred to the outputs until the next rising edge of
the Clock Pulse input.
Asynchronous Inputs:
LOW Input to Sd sets Q to HIGH level
LOW Input to Cd sets Q to LOW level
Clear and Set are Independent of clock
Simultaneous LOW on Cd and Sd makes both Q and Q HIGH
Industry Part Number
54F74
NS Part Numbers
54F74DMQB
54F74FMQB
54F74LMQB
Prime Die
M074
Processing
MIL-STD-883, Method 5004
Subgrp Description
1
2
3
4
5
6
7
8A
8B
9
10
11
Static tests at
Static tests at
Static tests at
Dynamic tests at
Dynamic tests at
Dynamic tests at
Functional tests at
Functional tests at
Functional tests at
Switching tests at
Switching tests at
Switching tests at
Temp (
o
C)
+25
+125
-55
+25
+125
-55
+25
+125
-55
+25
+125
-55
Quality Conformance Inspection
MIL-STD-883, Method 5005
1
