MICROCIRCUIT DATA SHEET

CN54F38-X REV 0A0

Original Creation Date: 10/21/98

Last Update Date: 11/12/98

Last Major Revision Date: 10/21/98

QUAD 2-INPUT NAND BUFFER (OPEN COLLECTOR)

General Description

The device contains four independent gates, each of which performs the logic NAND

function. The open-collector outputs require external pull-up resistors for proper

logical operation.

Industry Part Number

54F38

NS Part Numbers

54F38DC

Prime Die

M038

Processing

(blank)

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+70

0

+25

+70

0

+25

+70

0

+25

+70

0

Quality Conformance Inspection

(blank)

1
