MICROCIRCUIT DATA SHEET

CN54F373-X REV 0A0

Original Creation Date: 06/25/97

Last Update Date: 07/08/97

Last Major Revision Date: 06/25/97

OCTAL TRANSPARENT LATCH WITH TRI-STATE OUTPUTS

General Description

The F373 consists of eight latches with Tri-State outputs for bus organized system

applications. The flip-flops appear transparent to the data when Latch Enable (LE) is

HIGH. When LE is LOW, the data that meets the setup times are latched. Data appear on

the bus when the Output Enable (OE) is LOW. When OE is HIGH, the bus output is in the

high impedance state.

Industry Part Number

54F373

NS Part Numbers

54F373DC

Prime Die

M373

Processing

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+70

0

+25

+70

0

+25

+70

0

+25

+70

0
