MICROCIRCUIT DATA SHEET

CN54F253-X REV 0A0

Original Creation Date: 06/25/97

Last Update Date: 07/08/97

Last Major Revision Date: 06/25/97

DUAL 4-INPUT MULTIPLEXER WITH TRI-STATE OUTPUTS

General Description

The F253 is a dual 4-input multiplexer with Tri-State outputs. It can select two bits of

data from four sources using common select inputs. The outputs may be individually

switched to a high impedance state with a HIGH on the respective Output Enable (OE)

inputs, allowing the outputs to Interface directly with bus oriented systems.

Industry Part Number

54F253

NS Part Numbers

54F253DC

Prime Die

M253

Processing

(blank)

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+70

0

+25

+70

0

+25

+70

0

+25

+70

0

Quality Conformance Inspection

(blank)

1

next
