MICROCIRCUIT DATA SHEET

CN54F20-X REV 0A0

DUAL 4-INPUT NAND GATE

General Description

This device contains two independent gates, each of which performs the logic NAND

function.

Original Creation Date: 06/25/97

Last Update Date: 07/08/97

Last Major Revision Date: 06/25/97

Industry Part Number

54F20

NS Part Numbers

54F20DC

Prime Die

M020

Processing

(blank)

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+70

0

+25

+70

0

+25

+70

0

+25

+70

0

Quality Conformance Inspection

(blank)

1
