MICROCIRCUIT DATA SHEET

MN54ACTQ10-X REV 2A0

Triple 3-Input NAND Gate

General Description

The ACTQ10 contain three, 3- Input NAND gates and utilizes NSC Quiet Series technology to

guarantee quiet output switching and inproved dynamic threshold performance. FACT Quiet

Series features GTO output control and undershoot corrector in addition to a split ground

bus for superior ACMOS performance.

Original Creation Date: 07/11/96

Last Update Date: 04/27/99

Last Major Revision Date: 03/02/99

Industry Part Number

54ACTQ10

NS Part Numbers

54ACTQ10DMQB*

54ACTQ10FMQB**

54ACTQ10LMQB***

Prime Die

D010

Controlling Document

5962-92182

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

Quality Conformance Inspection

MIL-STD-883 5005

1
