MICROCIRCUIT DATA SHEET

MN54ACTQ08-X REV 2A0

Quad 2-Input AND Gate

General Description

The ACTQ08 contains Four, 2- input AND gates and utilizes NSC Quiet Series technology to

guarantee quiet output switching and improved dynamic threshold performance. FACT Quiet

Series TM features GTO TM output control and undershoot corrector in addition to a split

ground bus for superior ACMOS performance.

Original Creation Date: 07/11/96

Last Update Date: 04/27/99

Last Major Revision Date: 03/03/99

Industry Part Number

54ACTQ08

NS Part Numbers

54ACTQ08DMQB*

54ACTQ08FMQB**

54ACTQ08LMQB***

Prime Die

D008

Controlling Document

5962-89547

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

+25 C

+125 C

-55 C

Quality Conformance Inspection

MIL-STD-883 5005

1
