54ACT245FMQB Datasheet

  • 54ACT245FMQB

  • BUS TRANSCEIVER|SINGLE|8-BIT|ACT-CMOS|FP|20PIN|CERAMIC

  • 7頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MICROCIRCUIT DATA SHEET
MN54ACT245-X REV 1C0
Original Creation Date: 07/02/96
Last Update Date: 03/09/99
Last Major Revision Date: 07/02/96
Octal Bidirectional Transceiver With TRI-State
Inputs/Outputs
General Description
The ACT245 contains eight non-inverting bidirectional buffers with 3-state outputs and is
intended for bus-oriented applications. Current sinking capability is 24 mA at the A
ports and 24 mA at the B ports. The Transmit/Receiver (TR) input determines the direction
of data flow through the bidirectional transceiver. Transmit (active HIGH) enables data
from A ports to B ports. Receive (active LOW) enables data from B ports to A ports. The
Output Enable input, when HIGH, disables both A and B ports by placing them in a HIGH Z
condition.
Industry Part Number
54ACT245
NS Part Numbers
54ACT245DMQB
54ACT245FMQB
54ACT245LMQB
Prime Die
J245
Controlling Document
5962-87663
Processing
MIL-STD-883, Method 5004
Subgrp Description
1
2
3
4
5
6
7
8A
8B
9
10
11
Static tests at
Static tests at
Static tests at
Dynamic tests at
Dynamic tests at
Dynamic tests at
Functional tests at
Functional tests at
Functional tests at
Switching tests at
Switching tests at
Switching tests at
Temp (
o
C)
+25 C
+125 C
-55 C
+25 C
+125 C
-55 C
+25 C
+125 C
-55 C
+25 C
+125 C
-55 C
Quality Conformance Inspection
MIL-STD-883, Method 5005
1
