MICROCIRCUIT DATA SHEET

MN54AC241-X REV 1C1

Original Creation Date: 06/28/96

Last Update Date: 03/12/02

Last Major Revision Date: 06/28/96

Octal Buffers/Line Drivers With 3 - State Outputs

General Description

The AC241 is an octal buffer and line driver designed to be employed as a memory address

driver, clock driver and bus-oriented transmitter or receiver which provides improved PC

board density.

Industry Part Number

54AC241

NS Part Numbers

54AC241DMQB

54AC241FMQB

54AC241LMQB

54AC241WG-QML

Prime Die

Z241

Controlling Document

SEE FEATURES SECTION

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1

next
