Bulletin PD-20556 rev. B 05/02
52CPQ030
SCHOTTKY RECTIFIER
50 Amp
TO-247AC
Major Ratings and Characteristics
Characteristics
I
F(AV)
Rectangular
waveform
V
RRM
I
FSM
@ tp = 5 碌s sine
V
F
T
J
@ 25 Apk, T
J
= 125擄C
(per leg)
range
Description/Features
The 52CPQ030 center tap Schottky rectifier series has been
optimized for low reverse leakage at high temperature. The
proprietary barrier technology allows for reliable operation up
to 150擄 C junction temperature. Typical applications are in
switching power supplies, converters, free-wheeling diodes,
and reverse battery protection.
150擄 C T
J
operation
Center tap TO-247 package
High purity, high temperature epoxy encapsulation for
enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term
reliability
52CPQ030 Units
50
30
2180
0.38
A
V
A
V
- 55 to 150
擄C
15.90 (0 .626 )
15.30 (0 .602 )
3. 65 (0.144)
3. 55 (0 .139)
DIA.
5. 30 (0 .209)
4.70 ( 0.185)
2.5 ( 0.098)
1.5 ( 0.059)
5. 70 (0.225)
5.30 ( 0.208)
20 .30 (0.800)
19 .70 (0.775)
5.50 ( 0.217)
4. 50 (0 .17 7)
1
2
3
(2 PLCS.)
BASE
COMMON
CATHODE
2
14. 80 ( 0.583)
14 .20 (0 .559 )
1
2
3
4. 30 (0 .17 0)
3. 70 (0.14 5)
2. 20 (0 .08 7)
ANODE COMMON ANODE
CATHODE
1
2
1. 40 (0 .05 6)
2. 40 (0.095)
MAX.
0.80 ( 0.032)
0. 40 (0.213)
MAX.
1. 00 (0 .03 9)
10. 94 ( 0.430)
10 .86 (0.427)
Conform to JEDEC outline TO-247AC (TO-3P)
Dimensions in millimeters and inches
