AlGaAs/GaAs HIGH POWER T-1 3/4 PACKAGE
INFRARED EMITTING DIODE
Description
The MIE-524A4 is an infrared emitting diode utilizing
GaAs with AlGaAs window coating chip technology.
It is molded in water clear plastic package.
7.62
(.300)
MIE-524A4
Package Dimensions
蠁
5.05
(.200)
Unit : mm (inches )
5.47
(.215)
5.90
(.230)
1.00
(.040)
FLAT DENOTES CATHODE
Features
l
23.40 MIN.
(.920)
0.50 TYP.
(.020)
High radiant power and high radiant intensity
Suitable for DC and high pulse current operation
Standard T-1 3/4 (
蠁
5mm ) package, radiation angle : 20擄
Peak wavelength
位
p
= 940 nm
Good spectral matching to si-photodetector
l
l
1.00MIN
(.040)
2.54
(.100)
l
l
A
C
Notes :
1. Tolerance is 鹵 0.25 mm (.010") unless otherwise noted.
2. Protruded resin under flange is 1.5 mm (.059") max.
3. Lead spacing is measured where the leads emerge from the package.
Absolute Maximum Ratings
'@ T
A
=25
o
C
Parameter
Power Dissipation
Peak Forward Current(300pps,10碌s pulse)
Continuos Forward Current
Reverse Voltage
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
Maximum Rating
120
1
100
5
-55 C to +100 C
o
o
-55 C to +100 C
o
o
Unit
mW
A
mA
V
260
o
C for 5 seconds
Unity Opto Technology Co., Ltd.
11/17/2000
