PremierView 20ID
20.1" Multimedia TFT-LCD Monitor for Industrial, OEM and Desktop
Calibre specialises in high performance LCD
display solutions for industrial, OEM, military
and aerospace applications. PremierView
features flexible signal capability, excellent
motion reproduction and accurate, artifact
free image re-sizing.
Calibre's PremierView 20ID is a very high
performance TFT-LCD display.
Based
around Calibre's proprietary PremierView
LCD driver technology, it is able to connect
directly to a very wide range of video or
computer image sources and display images
full screen on its 20" viewable diagonal, wide
viewing angle screen.
PremierView is one of the most flexible LCD systems on the market able to accept a wide range of input
resolutions. PremierView features true autoscanning real-time software algorithms to allow it to be
adjusted to suit most non-standard resolutions and signal timings within its resolution, line and field rate
ranges.
PremierView 20ID displays real-time Video or computer VGA-SXGA full screen, full-motion in real time,
with minimal image throughput delay and no frame rate conversion. High performance scaling
algorithms work without compromising image quality or resolution irrespective of the signal resolution
implemented. It is compatible with Composite and Y/C (SVHS, S-video) inputs with automatic detection
of PAL, NTSC & SECAM video, and/or most computer RGB signals from 640x350 up to 1280x1024.
Very flexible wide-ranging picture controls are provided via an on-screen menu. These controls include
picture size and position controls as well as contrast, brightness, and colour/hue for video.
A special Slow-Scan model able to accept legacy industrial graphics signals down to 15KHz interlaced
or non-interlaced is also available. Compatibility with custom signal timings and resolutions can also be
provided as a customer specific option.
PremierView 20ID uses the latest high brightness 20.1" ultra-wide viewing angle 1280x1024 TFT-LCD
panel from NEC which features 250cd/m2 typical brightness, 24-bits per pixel and ultra-wide viewing
angles of 85 degrees left/right and up/down. When driven by PremierView, this ensures maximum
colour depth and accurate grey-scale reproduction, with no field merging, no field dropping or repetition
and no pixel or line dropping to ensure accurate motion reproduction and clean image scaling.
PremierView 20ID is available as a metal cased display unit or as an OEM open chassis module. The
metal cased display unit incorporates side mounting points. Cased units include an anti-scratch, anti-
glare front viewing window. Touchscreens are also available to special order.
