I27123 rev. C 02/03

50MT060ULS

"LOW SIDE CHOPPER" IGBT MTP

Ultrafast Speed IGBT

Features

鈥?Gen. 4 Ultrafast Speed IGBT Technology

鈥?HEXFRED

TM

Diode with UltraSoft

Reverse Recovery

鈥?Very Low Conduction and Switching

Losses

鈥?Optional SMT Thermistor (NTC)

鈥?Aluminum Nitride DBC

鈥?Very Low Stray Inductance Design for

High Speed Operation

鈥?UL approved ( file E78996 )

V

CES

= 600V

I

C

= 100A,

T

C

= 25擄C

Benefits

鈥?Optimized for Welding, UPS and SMPS

Applications

鈥?Operating Frequencies > 20 kHz Hard

Switching, >200 kHz Resonant Mode

鈥?Low EMI, requires Less Snubbing

鈥?Direct Mounting to Heatsink

鈥?PCB Solderable Terminals

鈥?Very Low Junction-to-Case Thermal

Resistance

MMTP

Absolute Maximum Ratings

Parameters

V

CES

I

C

I

CM

I

LM

I

F

I

FM

V

GE

V

ISOL

P

D

Collector-to-Emitter Voltage

Continuos Collector Current

Pulsed Collector Current

Peak Switching Current

Diode Continuous Forward Current

Peak Diode Forward Current

Gate-to-Emitter Voltage

RMS Isolation Voltage, Any Terminal to Case, t = 1 min

Maximum Power

Dissipation

Diode

IGBT

@ T

C

= 25擄C

@ T

C

= 100擄C

@ T

C

= 25擄C

@ T

C

= 100擄C

@ T

C

= 100擄C

@ T

C

= 25擄C

@ T

C

= 122擄C

Max

600

100

50

200

200

48

200

鹵 20

2500

445

175

205

83

Units

V

A

V

W

www.irf.com

1
