5082-2811 Datasheet

  • 5082-2811

  • Schottky Barrier Diodes for General Purpose Applications

  • 57.16KB

  • 6頁

  • AGILENT   AGILENT

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Schottky Barrier Diodes for
General Purpose Applications
Technical Data
1N5711
1N5712
5082-2300 Series
5082-2800 Series
5082-2900
Features
鈥?Low Turn-On Voltage
As Low as 0.34 V at 1 mA
鈥?Pico Second Switching Speed
鈥?High Breakdown Voltage
Up to 70 V
鈥?Matched Characteristics
Available
The 5082-2835 is a passivated
Schottky diode in a low cost glass
package. It is optimized for low
turn-on voltage. The 5082-2835 is
particularly well suited for the
UHF mixing needs of the CATV
marketplace.
The 5082-2300 Series and
5082-2900 devices are unpas-
sivated Schottky diodes in a glass
package. These diodes have
extremely low 1/f noise and are
ideal for low noise mixing, and
high sensitivity detecting. They
are particularly well suited for use
in Doppler or narrow band video
receivers.
Outline 15
0.41 (.016)
0.36 (.014)
25.4 (1.00)
MIN.
1.93 (.076)
1.73 (.068)
Description/Applications
The 1N5711, 1N5712, 5082-2800/
10/11 are passivated Schottky
barrier diodes which use a
patented 鈥済uard ring鈥?design to
achieve a high breakdown
voltage. Packaged in a low cost
glass package, they are well suited
for high level detecting, mixing,
switching, gating, log or A-D
converting, video detecting,
frequency discriminating,
sampling, and wave shaping.
4.32 (.170)
3.81 (.150)
CATHODE
25.4 (1.00)
MIN.
DIMENSIONS IN MILLIMETERS AND (INCHES).
Maximum Ratings
Junction Operating and Storage Temperature Range
5082-2303, -2900 .................................................................-60擄C to +100擄C
1N5711, 1N5712, 5082-2800/10/11 ....................................-65擄C to +200擄C
5082-2835 ............................................................................ -60擄C to +150擄C
DC Power Dissipation
(Measured in an infinite heat sink at T
CASE
= 25
擄
C)
Derate linearly to zero at maximum rated temperature
5082-2303, -2900 .............................................................................. 100 mW
1N5711, 1N5712, 5082-2800/10/11 ................................................. 250 mW
5082-2835 ......................................................................................... 150 mW
Peak Inverse Voltage ................................................................................. V
BR

5082-2811 產品屬性

  • 1N5711/12, 5082-2800 Series

  • Product Obsolescence 09/Jan/2008

  • 100

  • 分離式半導體產品

  • RF 二極管

  • -

  • 肖特基 - 單

  • 15V

  • 20mA

  • 1.2pF @ 0V，1MHz

  • -

  • 250mW

  • DO-204AH，DO-35，軸向

  • -

  • 散裝
