Typical
鈥?Nitride Passivated
Outline 01B
5082-0001
D
ALL OTHER CHIPS
D
X
X
Description
These PIN diode chips are silicon
dioxide or nitride passivated. The
5082-0001 has a mesa construc-
tion and the 5082-0012 has a
planar construction. The fabrica-
tion processes are optimized for
long term reliability and tightly
controlled for uniformity in
electrical performance.
X
X
Y
Y
DIMENSIONS
D
鹵0.03
(1)
X
鹵0.05
(2)
Y
鹵0.03
(1)
Top Contact
Applications
These general purpose PIN
diodes are intended for low
power switching applications
such as duplexers, antenna
switching matrices, digital phase
shifters, time multiplex filters, TR
switches, pulse and amplitude
modulators, limiters, leveling
circuits, and attenuators.
The 5082-0001 is optimized for
applications requiring fast
switching.
PART NO. 5082-
0012
0001
0.10
0.06
(4)
(2.5)
0.38
(15)
0.11
0.10
(4.5)
(4.0)
Au. Cathode Au. Anode
Bottom Contact Au. Anode Au. Cathode
Dimensions in millimeters (1/1000 inch)
Maximum Ratings
Junction Operating and Storage
Temperature Range ...................................................... -65擄C to +150擄C
Soldering Temperature
5082-0001 ....................................................... +300擄C for 1 min. max.
5082-0012 ....................................................... +425擄C for 1 min. max.
