鈥淓coline Series 504鈥?/div>
PLCC sockets are de-
signed for JEDEC type
substrates and will oper-
ate safely under normal
to moderately severe
conditions
Bottom cover is designed
to minimize danger of
flux wicking and brown
PPS insulator (RYTON R-4)
with ventilation zone un-
derneath component
greatly improves heat dis-
sipation
Ordering information
For standard part numbers please refer to table Order Codes
For PCB hole patterns see page 94
Plating
99
Stamped contacts
tin-lead over nickel
Please note: 99 is the only plating available for
this product.
No.
of
poles
Order Codes
Dimensions
A
1
20
28
*32*
44
52
68
84
100
504-99-020-24-000
504-99-028-24-000
504-99-032-24-000
504-99-044-24-000
504-99-052-24-000
504-99-068-24-000
504-99-084-24-000
504-99-100-24-000
* rectangular
15.56
18.10
18.10
23.18
25.72
30.80
35.88
A
2
15.56
18.10
20.64
23.18
25.72
30.80
35.88
B
1
B
2
C
1
C
2
9.62
11.90
14.40
17.00
19.50
24.65
29.65
E
18.06
21.70
23.70
28.50
32.46
39.94
47.00
5.08
5.08
9.62
7.62
7.62
11.90
7.62
10.16
11.84
12.70
12.70
17.00
15.24
15.24
19.50
20.32
20.32
24.65
25.40
25.40
29.65
not available from stock, please consult
1
