AS-i sensor/actuator module
Dimensions
31
90
66
80
102
Base is sold separately
Model number
VAA-4EA-G4-ZE/E2
G4 PG module IP67
4 inputs (PNP) and 4 electronic out-
puts
Electrical connection
Terminal block
Input
1
4
7
10
2
5
8
11
3
6
9
12
AUX+
AS-i
2
5
AS-i+
AS-i-
IN+
IN1
IN2
IN3
IN4
IN-
Terminal block
Output
OUT1
OUT2
OUT3
OUT4
1
OUT-
7
8
9 10 11 12
Cage clamp
terminal block
2
3 4
5
6
Load
Input or output
for 3-wire
sensors
Coupling Modules
8
U
廬
11
AUX
3
6
9
12
for
connection
of U
AUX
AUX+
AUX-
AUX-
Features
鈥?AS-Interface certificate
鈥?Protection degree IP67
鈥?Flat or round cable connection (via
standardised EEMS base, not in-
cluded in the delivery package)
鈥?Cable piercing method for flat cable
鈥?Communication monitoring, turn-
off
鈥?Inputs for 2- and 3-wire sensors
鈥?Power supply of outputs from the
external auxiliary voltage
鈥?Power supply of inputs from the
module
鈥?Function display for bus, ext. auxili-
ary voltage, inputs and outputs
鈥?Monitoring of sensor overloads
Indication/operating means
1 2 3 4 AS-i
1 2 3 4 AUX
Inputs
Outputs
Terminal block
Input
Terminal block
Output
22.01.2002
71
Subject to reasonable modifications due to technical advances.
Copyright Pepperl+Fuchs, Printed in Germany
