30 Watt NT Single Series DC/DC Converters
Features
!
!
!
!
!
!
!
Only 2.02" x 1.62" x 0.55" high
-40擄 to +90擄C case operating range standard
Very low OFF current, 1 mA typically
Transient overvoltage protected output
Overcurrent and overtemperature protection
Up to 86% efficiency
5 Year Warranty
Selection Chart
Description
These single output DC/DC converters are designed to provide
a wide range of PCB mount power solutions. The wide 2:1
input voltage range covers the common American and
European telecom standards.
For flexibility, a trim pin is included to adjust the output
voltage. Use it to compensate for voltage drops in your
system鈥檚 wiring or to achieve non standard voltages. Use the
remote ON/OFF function to maximize battery life.
The NT Single Series continues the CALEX tradition of
reliable design by including transient overvoltage suppressor
diode protection at the output terminals. Also provided as
standard are overcurrent and overtemperature protection
circuits. These features assure zero failure rate operation
when using the NT Single Series. All CALEX products are
backed by a 5 Year Warranty.
Model
48S5.5000NT
48S12.2500NT
48S15.2000NT
Input Range
VDC
Min
Max
36.0
36.0
36.0
72.0
72.0
72.0
Output
VDC
5.0
12.0
15.0
Output
mA
5000
2500
2000
25 - 30 Watt NT Single Series Block Diagram
SHIELDED
ISOLATION TRANSFORMER
THERMAL SHUTDOWN
A
D
4 + OUTPUT
C
+ INPUT 3
- INPUT 2
CURRENT
MODE
PWM
5 CMN
6 TRIM
ISOLATED
FEEDBACK
ON/OFF 1
Output
C
D
5
12
15
270碌F
40碌F
40碌F
6.8V
15V
18V
FIVE-SIDED SHIELDED COPPER CASE
LOW TC
BANDGAP REFERENCE
