Sola 2000
Guide Specifications
Fax-on-Demand # 8221
Uninterruptible Power Supply Systems - Sola 2000
Guide Specifications for a Sola2000 250 to 600 VA
Single - Phase Uninterruptible Power Supply System
1.0
1.1
GENERAL
SUMMARY
This specification defines the electrical and mechanical characteristics and requirements for a continuous-
duty single-phase, solid state, uninterruptible power supply system. The uninterruptible power supply system,
hereafter referred to as the UPS, shall provide continuous AC power for sensitive electronic equipment loads.
1.2
STANDARDS
The UPS shall be designed in accordance with the applicable sections of the current revision of the following
documents. Where a conflict arises between these documents and statements made herein, the statements
in this specification shall govern.
115V Units
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
UL Standard 1778
UL Standard 1449
FCC Part 15, Subpart B, Class B
IEEE 587, Category A and B
C-UL (CAN\CSA 22.2 No. 107.1)
230V Units
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
1.3
EN 50091-1
EN 55022, Class B
IEC 801-2
IEC 801-3
IEC 801-4
IEC 801-5
EN60950
EN50091-1
CE compliance mark
EMC Directive 89/336/EEC
SYSTEM DESCRIPTION
1
Fax-on-Demand: (877) 888-9329, Document #: 8221
Contact Technical Services at (800) 377-4384 with any questions.
