M I C R O T U N E鈩?/div>

4737 PY5 RF T

UNER

ODULE

7180, 3

8568)

DVANCE

ATA

HEET

1 APPLICATIONS

ABLE

ODEM

PPLICATIONS

The 4737 PY5 RF Tuner Module is designed for subscriber-side cable modem

applications.

2 FEATURES

鈥?/div>

EuroDOCSIS compatible

VHF Low, VHF High, and UHF

All functions controlled by I

C bus

Downstream frequency range from 80 MHz to 860 MHz

Upstream frequency range from 5 MHz to 65 MHz

Antenna input: F-connector

3 INTRODUCTION

The 4737 PY5 RF Tuner Module covers a frequency range from 80 MHz to 860 MHz

with a channel bandwidth of 6 MHz for downstream signals, and 5 MHz to 65 MHz

for upstream signals.

Figure 1

4737 PY5 RF Tuner Module

The receiver uses a single-conversion approach with the reception frequency range

divided into VHF low, VHF high, and UHF.

Band selection and tuning is done via the I

C -bus. An automatic gain control (AGC)

input allows for external control of the output signal amplitude.

3X 7180 ED Revision: 02

August 00

Page 1 of 14

7180ED02.doc
