RL28-8-H-700-../105/...

Reflection light scanner with background suppression

RL28-8-H-700-../105/...

with 5-pin, M12 x 1 plastic connector

廬

Sensor range 20 mm ... 700 mm, adju-

stable

PNP and NPN transistor outputs

Clearly visible LEDs for Power ON,

switching state and stability control

Not sensitive to ambient light, even

with energy saving lamps

Design RT: Good alignability by red

transmission LED

Design IR: Minimal black-white diffe-

rence through the infrared transmis-

sion LED

Dove-tail mounts and pass-through

mounting holes

Large temperature range from

-40 擄C ... +60 擄C

Waterproof, protection class IP67

Series

For suitable cable sockets, reflectors and mounting aids refer to chapter "accessories".

Subject to reasonable modifications due to technical advances.

Pepperl+Fuchs Group 鈥?Tel.: Germany (06 21) 7 76-0 鈥?USA (330) 4 25 35 55 鈥?Singapore 7 79 90 91 鈥?Internet http://www.pepperl-fuchs.com

Date of issue:

10/4/01
