HCC/HCF4043B
HCC/HCF4044B
QUAD 3-STATE R-S LATCHES
QUAD NOR
QUAD NAND
.
.
.
.
.
.
.
.
R-S LATCH-4043B
R-S LATCH-4044B
QUIESCENT CURRENT SPECIFIED TO 20V
FOR HCC DEVICE
3-LEVEL OUTPUTS WITH COMMON OUTPUT
ENABLE
SEPARATE SET AND RESET INPUT FOR
EACH LATCH
5V, 10V, AND 15V PARAMETRIC RATINGS
NOR AND NAND CONFIGURATIONS
INPUT CURRENT OF 100nA AT 18V AND 25擄C
FOR HCC DEVICE
100% TESTED FOR QUIESCENT CURRENT
MEETS ALL REQUIREMENTS OF JEDEC TEN-
TATIVE STANDARD N擄 13A, 鈥漇TANDARD SPE-
CIFICATIONS FOR DESCRIPTION OF 鈥滲鈥?/div>
SERIES CMOS DEVICES鈥?/div>
EY
(Plastic Package)
F
(Ceramic Frit Seal Package)
M1
(Micro Package)
C1
(Plastic Chip Carrier)
ORDER CODES :
HCC40XXBF
HCF40XXBM1
HCF40XXBEY
HCF40XXBC1
PIN CONNECTIONS
4043B
DESCRIPTION
The
HCC4043B, HCC4044B,
(extended tempera-
ture range) and the
HCF4043B, HCF4044B
(inter-
mediate temperature range) are monolithic
integrated circuits, available in 16-lead dual in-line
plastic or ceramic package and plastic micropack-
age. The
HCC/HCF4043B
types are quad cross-
coupled 3-state COS/MOS NOR latches and the
HCC/HCF4044B
types are quad cross-coupled 3-
state COS/MOS NAND latches. Each latch has a
separate Q output and individual SET and RESET
inputs. The Q outputs are controlled by a common
ENABLE input. A logic 鈥?鈥?or 鈥漢igh鈥?on the ENABLE
input connects the latch states to the Q outputs. A
logic 鈥?鈥?or 鈥漧ow鈥?on the ENABLE input disconnects
the latch states from the Q outputs, resulting in an
open circuit condition on the Q outputs. The open
circuit feature allows common bussing of the out-
puts.
June 1989
4044B
1/13
