Dual Trip Amplifiers
The 4002ALM trip-amplifier can accept a wide range of
input types. The unit can have up to two relay outputs and
can also produce an isolated 4-20mA retransmission output
s
s
s
s
s
Wide range of configurable inputs
Configurable trip action with fail-safe modes
Optional isolated re-transmission
Optional isolated transmitter supply
Optional LED display or 0-10V signal output of input and
setpoints values
4002ALM
Options and ordering codes
4002ALM HL 鈥?A A
Input type
4-20mA
0-20mA
0-30mA 2 sec delay
0-1mA
0-5Vdc
1-5Vdc
0-10Vdc
18-26Vdc
Type K 0-150藲C
Type K 0-200藲C
Type K 0-250藲C
Type K 0-500藲C
Type K 0-600藲C
Type K 0-1200藲C
Type J 0-250藲C
Pt100 3 wire 鹵100藲C
Pt100 3 wire 鹵50藲C
Pt100 3 wire 鹵30藲C
Pt100 3 wire 0-50藲C
Pt100 3 wire 0-100藲C
Pt100 3 wire 0-150藲C
Pt100 3 wire 0-200藲C
Pt100 3 wire 0-250藲C
Pt100 3 wire 0-400藲C
XX 鈥?4 AB
Options
HL
HL
HL
HL
HL
HL
HL
HL
TC
TC
TC
TC
TC
TC
TC
RTD
RTD
RTD
RTD
RTD
RTD
RTD
RTD
RTD
A
A
B
C
D
E
F
G
H
P
Q
R
S
T
U
W
Y
Z
1
2
3
4
5
6
7
A
X
4
6
B
AB
LED
display
Tx supply
LED and
Tx supply
Supply type
230/115Vac
24Vdc
Output options
4-20mA re-transmission
No re-transmission
PRICE
INFORMATION
AND ORDERING
Other ranges and thermocouple
types are available as detailed in the
product description, please contact
our sales department.
